Bridge Rectifier - 5 Amp / 100V - Eisco Labs

• Convert AC input to DC output!
• Circuit diagram printed on unit provides visual understanding of function
• Great for student use!
• 4mm inputs
• 5 x 3.5 x 1.5" dimensions

EISCO Bridge Rectifier consists of four diodes connected in a bridge circuit. The most common application of this circuit is the conversion of alternating current (AC) input into direct current (DC) output. The unit has a circuit diagram printed so that student may gain an appreciation of the importance of diodes and how they can rectify alternating current to direct current. Current : 5 Amp / 100 V
